LEAN DL

  • Rotating
  • Tilting
  • Reflectors: 10D, 30D, 50D, 20D, 40D, 60D
  • Available Drivers: ON/OFF, Dali, Casambi

Technical data

Input Power LED-Module Color Consistency Installation Type Material Lumen Maintenance Luminaire Color
220 – 240V PHILIPS – SAMSUNG – CITIZEN 2-Step MacAdam Downlight Powder Painted Die-Cast Aluminum 50 000h L80 B10 White (RAL 9016) Silver (Ca. RAL 9006) Black (RAL 9005)
COB Type Forward Current System Luminous Flux Total System Power Total System Power
CRI 90 3000K 350mA 1726Lm 13,9 W 124.0
CRI 90 3000K 650mA 3090Lm 25,4 W 121.6
CRI 90 3000K 850mA 3936Lm 33,7 W 116.8
CRI 90 4000K 350mA 1815Lm 13,9 W 130.6
CRI 90 4000K 650mA 3265Lm 25,4 W 128.5
CRI 90 4000K 850mA 4170Lm 33,7 W 123.7
