First Single DL

  • Tilting
  • High performance
  • Classic design
  • Reflectors: 10D, 30D, 50D, 20D, 40D, 60D
  • Available Drivers: ON/OFF, Dali, Casambi

Technical data

Input Power LED-Module Color Consistency Installation Type Installation Type Lumen Maintenance Luminaire Color
220 – 240V PHILIPS – SAMSUNG – CITIZEN 2-Step MacAdam Downlight Power Painted Die-Cast aluminium 50 000h L80 B10 White (RAL 9016),Black (RAL 9005), Silver (Ca. RAL 9006)
COB Type Forward current System Luminous Flux System Power Lm/W
CRI 90 3000K 250mA 1 240 lm 10,0 W 124.0
CRI 90 3000K 650mA 3 090 lm 25,4 W 121.6
CRI 90 3000K 1 050ma 4 736 lm 41,8 W 113.0
CRI 90 4000K 250mA 1 300 lm 10,0 W 130.0
CRI 90 4000K 650mA 3 265 lm 25,4 W 128.5
CRI 90 4000K 1 050mA 5 030 lm 41,8 W 120.4
