DINGO PRO DL

  • Rotating
  • Tilting
  • Light Channel
  • Thermally Strong
  • Reflectors: 15D, 28D, 50D
  • Available Drivers: ON / OFF, Dali, Casambi

Technical data

Input Power LED-Module Color Consistency Installation Type Material Lumen Maintenance Luminaire Color
220-240V PHILIPS- SAMSUNG- CITIZEN 2-Step MacAdam Downlight Powder Painted Die-Cast Aluminum 50 000h L80 B10 White (RAL 9016) Silver (Ca. RAL 9006) Black (RAL 9005)
COB Type 1208 Forward current System Luminous Flux System Power Lm/W
CRI 90 3000K 250mA 1 240 lm 10,0 W 124.0
CRI 90 3000K 650mA 3 090 lm 25,4 W 121.6
CRI 90 3000K 1 050mA 4 736 lm 41,8 W 113.3
CRI 90 4000K 250mA 1 300 lm 10,0 W 130.0
CRI 90 4000K 650ma 3 265 lm 25,4 W 128.5
CRI 90 4000K 1 050mA 5 030lm 41,8 W 120.4
